ATCA CO6 AC-DC 6 Slot 6U

Front to top:
技术: AdvancedTCA
插槽: 6
冷却: Side to side
能量显示: AC, DC

ABOUT THE PRODUCT

The AdvancedTCA® CO6, 6-slot chassis, AC-DC version combines high cooling capability with the high data throughput.

Compliancy:

• PICMG 3.0 Rev 3.0
• RoHS
• Designed to meet NEBS
• UL/cUL/CE

AC Input option:

• Up to 4 redundant Power Supply units (PSU), 4.4kW overall power
• Each PSU rated 1100W@220VAC
• Up to 3.3kW redundant power
• PSU redundancy: N+1 (3+1)

features

  • 19”, 6U Rackmount chassis
  • Accommodates 6 ATCA front boards and RTMs
  • Side-to-side cooling topology with 450W per slot cooling, front + RTM
  • Push-Pull cooling with 2 hot-swappable redundant fan trays
  • Equipped with breakthrough 40Gbps Air-/-Plane backplane technology
  • Dual Star, Dual-Dual Star, or Full Mesh backplane topologies
  • Power distribution beyond 500W per slot
  • DC Input option: 2 redundant Power Entry Modules with filtering
  • Redundant Pigeon Point SHMM700 Shelf Manager
  • High Reliability bussed IPMB
