CompactPCI 2 Slot 1U

Technology: CompactPCI
Slots: 2
Cooling: Side to side
Power: AC, DC


1U, 19″ Rackmount system with hot removable CPCI 3U Power Supply, four Powerful Fans and CompactPCI Backplane. The system support 6U cards Front and Rear. Additional four fans are available for optimal Front and RTM cooling solution. The Backplane is compliant with PICMG 2.0 R3.0 with 64bit 66MHz & supports boards with hot swap capability PICMG 2.1 R2.0. All five CompactPCI connectors (J1-J5) are available on the backplane. The system slot is located on the lower-slot.


Customer specific assembly version on request


  • 19" Rackmount. Chassis 1U high, Black
  • Horizontally mounted 6U 160mm boards and rear I/O 80mm
  • CompactPCI Backplane 2 slots 64bit, 66Mhz
  • EMC and ESD optimized steel construction
  • IEEE front and rear card guides
  • Hot swap CompactPCI power supplies AC wide range or 48VDC
  • Active heat dissipation of the boards via convection from side to side
  • Variable cooling solution by the use of up to 8 fans
  • Four Powerful fans40 x40mm with fan fail LED on front
  • Optional additional 3 fans for push-pull cooling
  • Optional additional 1 fans for push-pull cooling for RTM
